Products Details


GENERAL SERVICE VALVE


(Pneumatics)

Product Name : ASCO 210 GENERAL SERVICE VALVE
Brand : ASCO
Part No: WPT210C094V
Size: 1/2"
Model No: WPT210C094V
Description : ASCO WEATHERPROOF S...More

Product Name : GENERAL SERVICE VALVE
Brand : ASCO
Part No: 8210G004 240/60,220/50
Size: 1"
Model No: 8210G004 240/60,220/50
Description : Solenoid Valve - 2 ...More

Product Name : GENERAL SERVICE VALVE
Brand : ASCO
Part No: 8210G095 120/60,110/50
Size: 3/4"
Model No: 8210G095 120/60,110/50
Description : Solenoid Valve - 2 ...More

Product Name : GENERAL SERVICE VALVE
Brand : ASCO
Part No: EF8320G184 110/50
Size: 1/4"
Model No: EF8320G184 110/50
Description : Solenoid Valve - 3 ...More

Product Name : GENERAL SERVICE VALVE
Brand : ASCO
Part No: 8551G466
Size: 1/4"
Model No: 8551G466
Description : Solenoid Valve - 3 ...More

Product Name : GENERAL SERVICE VALVE
Brand : ASCO
Part No: EV8551H309 24/DC
Size: 1/4"
Model No: EV8551H309 24/DC
Description : 5/3 spool valve Vol...More

Product Name : GENERAL SERVICE VALVE
Brand : ASCO
Part No: 8314H053
Size: 1/4"X3/32
Model No: 8314H053
Description : Solenoid Valve - 3 ...More

Product Name : GENERAL SERVICE VALVE
Brand : ASCO
Part No: 8320G184 24/DC
Size: 1/4"
Model No: 8320G184 24/DC
Description : Solenoid Valve - 3 ...More

Product Name : GENERAL SERVICE VALVE
Brand : ASCO
Part No: 8344G070MO
Size: 1/4"
Model No: 8344G070MO
Description : Solenoid Valve - 4 ...More

Product Name : STEAM VALVE
Brand : ASCO
Part No: SCE222B095
Size: 3/4"
Model No: SCE222B095
Description : ASCO STEAM SOLENOID...More

General Service Solenoid Valves



ASCO general service valves control the flow of neutral gases. They are known for their long life and fast response time available in multiple mounting configurations.



The solenoid is an electromagnetic part of a valve, comprised of a coil, core tube, core and enclosure. The ASCO RedHat brand offers the world’s largest selection of 2-way, 3-way and 4-way solenoid valves, designed to handle the most demanding fluid control applications.

ASCO's 2-Way solenoid valves have one inlet and one outlet, and are used to permit and shut off fluid flow. The two types of operations are Normally Closed (NC) and Normally Open (NO). Two types of constructions apply to 2-way solenoid valves, which are direct acting and internally piloted.
With Direct acting constructions, the solenoid is energized, the core directly opens the orifice of a Normally Closed valve or closes the orifice in a Normally Open Valve. The valve will operate at pressures from 0 psi to its rated maximum.
Internally piloted constructions use line pressure to assist operation. When the coil is de-energized (on a Normally Closed Valve), the pilot orifice is closed and line pressure is applied to the top of the piston or diaphragm through the bleed orifice, closing the valve.

ASCO 3-Way Solenoid Valves have three pipe connections and two orifices. When one orifice is open, the other is closed and vice versa. They are commonly used to alternately apply pressure to an exhaust pressure from a valve actuator or a single acting cylinder. These valves can be normally closed, normally open or universal.

ASCO 4-Way Solenoid Valves have four or five pipe connections, commonly called ports. One pressure inlet, two cylinder ports providing pressure to the double acting cylinder or actuator and one or two outlets to exhaust pressure from the cylinders. They have three types of construction, single solenoid, dual solenoid or single air operator.
